BHS - BROCKHAUS high-performance steel
Efficiency is a decisive factor in the modern automotive industry. BROCKHAUS high-performance steel (BHS) is the answer when it comes to material efficiency. It combines high component strength with excellent formability, offering simultaneous weight and cost advantages.
BHS
Mechanical properties
| Rp0,2, longitudinal [MPa] | Rm, longitudinal [MPa] | A80 [%] | |
| BHS 600 | ≥ 600 | 650 – 800 | ≥ 12 |
| BHS 700 | ≥ 700 | 750 – 900 | ≥ 10 |
| BHS 800 | ≥ 800 | 850 – 1.000 | ≥ 8 |
| BHS 1000 | ≥ 1000 | 1050 – 1200 | ≥ 5 |
*Continuous adjustment of the minimum yield strength from 500 to 1200 MPa possible
Surface
Type: MA / MB
Finish: RL / RM, mill-oiled
Other
Tolerances: unless otherwise specified, tolerances according to EN 10140 apply.
Delivery condition: GK (cut edge)
Technical Features
Trademark
The special mill grade “BHS” is based on micro-alloyed fine-grain steels and is characterized by high strength and the resulting pronounced wear resistance.
A key advantage is that no subsequent heat treatment is required to achieve the desired performance properties. This eliminates distortions that could otherwise significantly affect shape and positional tolerances.
Despite their very high strength and a yield strength ratio (Rp₀.₂/Rm) of up to 95%, BHS grades maintain sufficient formability for a wide range of manufacturing processes.
Thanks to the combination of high strength and toughness, weight savings of up to 50% can be achieved in the final product.
BHS 600
BHS 700
BHS 800
BHS 1000
BHS
BROCKHAUS high-performance steel
Advantages
