BROCKHAUS certified reference sample

The quality requirements for hard and soft magnetic materials are constantly increasing. Therefore, quality controls are becoming more and more important both during production and further processing. In addition to the development, production and marketing of hard and soft magnetic measuring instruments, we therefore offer the service for contract measurements of sample material in our measuring laboratory.

You should take the benefit from having your Epstein and Sheet Samples (500 x 500 mm) calibrated according to international standards in our calibration laboratory and using them as a reference for your application. Use this opportunity and get your reference samples calibrated in our laboratory DAkkS-accredited acc. to DIN EN ISO/IEC 17025:2018.

To ensure the comparability of the test results, it is necessary to calibrate the measuring systems according to internationally recognized standards. The basis for all calibrations of the hard and soft magnetic BROCKHAUS measuring systems are the measurements of the international SI units voltage, current and frequency as well as nuclear magnetic resonance.

BROCKHAUS meets these increasing demands on test equipment by continuously and gradually revising existing measuring systems and developing new measuring methods.

Measurements as a service

• Measurements of hard and soft magnetic materials, e.g. electrical steels, amorphous materials, powder composites, stators, rotors, magnetic assemblies
• Calibration of material samples
• Calibration and re-calibration of measuring instruments
• Reference samples calibrated in our calibration laboratory accredited acc. to DIN EN ISO/IEC 17025:2018 (Epstein and sheet samples 500 x 500 mm)

Soft magnetic materials

All measurements acc. to IEC and other international standards like ASTM, JIS, e.g.

• Epstein testing acc. to DIN IEC 60404-2:2008-06**
• Sheet samples 500 x 500 mm acc. to DIN IEC 60404-3:2010-04**
• Ring core measurement acc. to IEC 60404-4

Coercive field strength of magnetic materials in an open magnetic circuit acc. to IEC 60404-7

Franklin Test acc. to IEC 60404-11

Individual measurements on single laminations, stripes, sheets and rings

Measurements under special treatments like tension/pressure or different temperatures

Ring and stator measurement in various production stages

Stator core measurement via different stator segments comprising teeth and sections of back iron (relative magnetic properties in teeth)

Single-tooth measurement of stators

Magnetostriction measurement

Hard magnetic materials

Measurement of permanent magnets in an electromagnet acc. to IEC 60404-5

Measuring under temperature in the range of -45°C up to 200°C

Individual measuring setup of testing rotors with permanent magnets

Measurement of magnetic flux density, field strength and magnetic stray field by scanning the magnetic surface of permanent magnets and rotors

Measurement of the magnetic moment and angle error of magnetic axis vs. mechanical axis

Eddy current losses test

Magnetizing service

* BROCKHAUS device used for the measurement
** also available in our calibration laboratory accredited by DAkkS acc. to DIN EN ISO/IEC 17025:2018
